Fuel Pump Ring, 2005 - 2018 TJ / LJ / JK

1 review Write a Review

ARP-1001 GenRight Fuel Pump ring (and nut) for a 2005 - 2018 Jeep pump module


This is the fuel pump adapter ring for any 2005 - Current factory type fuel pump modules on the Jeep TJ, LJ, and JK.

The GenRight Crawler™ Series Fuel Pump Tank rings are great for adapting your factory pump to other aftermarket tanks (metal or plastic).

It is specifically designed and CNC machined from 6061 aluminum alloy to fit the factory fuel pump (includes a machined mating top nut, as pictured) that came in Jeeps between 2005 and 2018.

The 2 piece design is easy to install once the hole is cut and bolt holes drilled.

The APR-1001 model pump ring kit, re-uses the big factory o-ring under the fuel pump and includes a new machined top locking nut.

Great for RCI and JAZ fuel cells.

Includes mounting hardware as shown.


  • Not approved for highway use!
  • Mounting ring is machined to the same overall height as stock.
  • Requires cutting and drilling (on new tanks only) to install properly.
  • Requires a gasket or fuel proof silicone sealant between the pump ring plate and the tank surface.
  • We also offer an APR-1000 for the older model Jeep fuel pump models '97-'04.
  • Works with GenRight Aeromotive Phantom adapter too!

1 Review

  • 5
    Fuel Pump Ring

    Posted by Mike Condit on Feb 26th 2018

    Simple installation and works perfectly in my RCI fuel cell. Unscrew pump out of the old tank and right into the new fuel cell.
