MADE IN THE USA

Johnny Joint for Upper Link on Axle

$73.00
No reviews yet Write a Review

Johnny Joint for Upper Link on Axle

P/N:
CE-9112M2

This is the specially machined Johnny Joint® rod end out of the Currie CE-9102K front end housing kit.

This joint's outer shell is machined to a 1.795" outer diameter with a flanged edge and is designed to be pressed into the "EAR" on the top of front differential housing casting.

Will fit a JK/TJ/LJ/XJ/MJ Dana 30 or 44 frontend housings and is designed to replace the stock rubber bushing on the axle side of the upper control arm.

Includes a new 1/2" Grade 8 greasable bolt, washers and Unitorque nut.

FEATURES:

  • Proven Currie Johnny Joint product design
  • Design helps to isolates noise from transferring into chassis.
  • Overall width is 2-5/8"
  • Uses a 1/2" Grade 8 bolt.
  • 30 degrees of rotation.
  • Rebuildable.
  • Greaseable.


NOTE:

  • Sold individually.



Be sure to click on "MORE PICTURES" to see larger more detailed images of this product.
