Rear Cross Member Plate, CJ-7

$249.99
No reviews yet Write a Review

RBB-1008 Rear Cross Member Plate for a Jeep CJ-7

P/N:
RBB-1008

This is the GenRight RBB-1008, a 3/16" thick steel cross member re-enforcement plate to "cap" the factory rear frame cross member on a Jeep CJ-7.

It is designed to beef-up your existing rear frame member AND rear most body mounts. It can also be used as a hi clearance bumper by itself (as we do on our swing down tire carriers) or a re-enforcement under any rear bumper.

Remove the rear most body mounts and install the plate then slip them back in place.

FEATURES:

  • Allows you to repair or replace damaged rear cross members & body mounts.
  • Allows you to beef up the old (and in most cases rusty) factory 1/8" thick rear frame section.
  • Can be installed under an existing rear bumper.
  • Can be used by itself as a bumper for a better departure angle.
  • Bolt-on design
  • Shipped to you un-painted


This kit includes:

  • (1) Full width laser cut and CNC bent rear plate
  • Mounting  hardware


IMPORTANT NOTES:

  • Requires drilling additional holes in the rear cross member to properly mount it on your Jeep.
  • For proper mounting, it requires removing the fuel tank to drill and access center bolts.
  • Will NOT work on YJ's or TJ's. Please use p/n: RBB-1000 for those applications.
  • If this product is being used under a aftermarket rear bumper to beef up or re-inforce the rear cross member, you may have to cut off and re-weld the lower tabs on the rear bumper (if your bumper has these).
